Epson SureLab D3000 - Double Roll Administrator's Guide

Settings/Maintenance
32
Printing the check pattern
Print a check pattern, and then check for clogged nozzles. Perform Print Head Unit cleaning according to the check
results.
A
Select the roll paper feeder you want to use for printing.
This can be selected when paper is loaded.
B
Click Print Check Pattern.
The check pattern is printed.
C
Check the print results.
See the illustration below for more information on reading the print results.
If there are any gaps in the check pattern, you need to perform head cleaning.
Result: Good
There are no gaps in the check pattern. The nozzles are not clogged.
Result: Nozzles are clogged
There are gaps in the check pattern. Nozzles are clogged. Perform cleaning.
Tip:
The numbers under the check pattern (1, 2, 3, ...) indicate the head number.

Epson SureLab D3000 - Double Roll Specifications

General

Max Print Resolution	1440 x 1440 dpi
Number of Ink Colors	6
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta
Connectivity	USB 2.0, Ethernet
Print Technology	Inkjet
Max Print Size	12 x 48 inches
Print Speed (4x6)	360 prints per hour
Roll Media Width	4", 8", 12"
