Epson SureLab D3000 - Double Roll Administrator's Guide

Settings/Maintenance
57
E
Click Print from Print Adjustment Pattern.
Displays the screen setting the amount of change in the printed adjustment pattern.
F
Select Adjustment Pattern Shift Value, and then click Print.
Select the larger value to print the adjustment pattern which indicates large differences between each
adjustment value.
To make fine adjustments, select a lower value.
Select the amount of change for P1 (Shadow), P2 (Half-tone), and P3 (Highlight) according to the brightness
point.
The adjustment pattern is printed.
G
Select the best pattern from the adjustment pattern, and check the adjustment values.
The adjustment value is printed in letters and numbers at the bottom left of each pattern. (Example: R-2)
The letter indicates the direction of the adjustment color. "N" means no correction.
The number shows the amount changed.
Check P1 (Shadow), P2 (Half-tone), and P3 (Highlight) according to the brightness point.

Epson SureLab D3000 - Double Roll Specifications

General

Max Print Resolution	1440 x 1440 dpi
Number of Ink Colors	6
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta
Connectivity	USB 2.0, Ethernet
Print Technology	Inkjet
Max Print Size	12 x 48 inches
Print Speed (4x6)	360 prints per hour
Roll Media Width	4", 8", 12"
