Epson T88IIIP - TM B/W Thermal Line Printer User Manual

2-4 Setup Rev. A
For details on DIP SW2-1: BUSY conditions, also refer to “Busy State” (page 3-11).
Table 2-2 Baud rate selection (DIP SW1-7, 1-8)
TM-T88II TM-T88III
Baud rate
(BPS)
Switch no.
Baud rate
(BPS)
Switch no.
1-7 1-8 1-7 1-8
2400 ON ON 38400 ON ON
4800 OFF ON 4800 OFF ON
9600 * ON OFF 9600 * ON OFF
19200 OFF OFF 19200 OFF OFF
Table 2-3 Switch bank 2 settings
SW Function ON OFF
2-1 Handshake (BUSY) conditions Receive buffer full Printer offline or
receive buffer full *
2-2 Reserved (do not change setting) Fixed to OFF
2-3, 2-4 Print density selection/low-power mode (See separate table.)
2-5 Conditions for canceling receive buffer BUSY state (See separate table.)
2-6 Reserved (do not change setting) Fixed to OFF
2-7 Pin # 6 reset signal Used Not used *
2-8 Pin # 25 reset signal Used Not used *
Table 2-4 Print density selection (DIP SW2-3, 2-4)
Level Print density
Switch No.
2-3 2-4
—Low-power modeONON
1 Regular print density * OFF OFF
2
↔
ON OFF
3 Heavy print density OFF ON
Table 2-5 Conditions for canceling receive buffer BUSY state (DIP SW2-5)
TM-T88II TM-T88III
Conditions to cancel receive buffer
BUSY state
Switch No. Conditions to cancel receive buffer
BUSY state (enabled only when DIP
SW1-2 is OFF)
Switch No.
2-5 2-5
BUSY state canceled when 26 bytes or
more remain in receive buffer
Fixed to
OFF
BUSY state canceled when 138 bytes
remain in receive buffer
ON
BUSY state canceled when 256
bytes * remain in receive buffer
OFF

Epson T88IIIP - TM B/W Thermal Line Printer Specifications

General

Brand	Epson
Model	T88IIIP - TM B/W Thermal Line Printer
Category	Printer
Language	English
