185
Appendix
Media type Plain label/ Matte label/ Synthetic label/ Glossy label
Media source Roll paper
Backing paper width 50 mm to 112 mm {1.97 to 4.41"}
Label width 46 to 108 mm {1.81 to 4.25"}
Label length 25.4 to 600 mm {1 to 23.62"}
Gap between labels 3 to 6 mm {0.12 to 0.24"}
Left and right outer edges 2 0.5 mm {0.08 0.020"}
Label edge R 1.5 mm {0.06"} or less
Width of a black mark 28 mm {1.10"} or more from paper edge
Length of a black mark 5 mm {0.20"} or more
Black mark position Right edge of back of paper, when feed edge is at top
Gaps between black marks 28.4 to 606 mm {1.12 to 23.86"}
Paper thickness Plain label/ Matte label:
0.129 to 0.236 mm {0.006 to 0.009"} (reference values)
Glossy label:
0.167 to 0.182 mm {0.007 to 0.007"} (reference values)
Paper core Internal diameter: 76.2 0.5 mm {3 0.020"}
External diameter: 82.2 mm {3.24"} or more
External diameter Maximum 203.2 mm {8"}
Winding direction Printing face must be facing outside.
Do not use the paper with a hole or cutout.
For the black mark position of the die-cut label paper, match the label edge to the black
mark edge.
