Epson TM-P20 User Manual

E
Select the printer to be paired (Not been paired yet) and click Connect.
F
If the window to enter a passkey appears, enter a passkey and click OK.
Initial passkey: 0000
G
The "Assign port" window appears. Select the port to be used from the pull-down list and click OK.
H
The "Connection complete" window appears. Click Test Buzzer or Test Printing to check operation.
The printer buzzer sounds or printing starts.
!
Caution:
If TM Bluetooth Connector Status is " x" after pairing, check the followings.
❏ The printer power source is 10 m or less away from the computer power source.
❏ There is no other wireless device, such as a microwave oven and cordless telephone, that can interfere
with the Bluetooth printer.
❏ The printer and the computer are in the same room.
❏ The TM Bluetooth Connector search time is not set short.
❏ The printer to be detected is not communicating with any computer.
If TM Bluetooth Connector Status is " Not been paired yet", check the following.
❏ The printer is not paired. Perform pairing again.
I
Click the "x" button of TM Bluetooth Connector to exit.
TM-P20 Software Installer Software User's Manual
Installation
26

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
