Installing
the Paper Roll
Use a paper roll that matches the specifications.
,
Q3
Note:
The
printer must be turned on before installing
the
paper roll.
1.
Fold the paper so it is exactly straight and even, as shown in the
illustration, and will not tear off jaggedly.
No
No
Correct
2.
Turn on the printer, open the printer cover, and remove the take-up
spool.
3.
Insert the paper roll as shown below.
4.
Insert the tip of the paper into the paper inlet as far as it will go, and
push the PAPER LOAD switch
to feed the paper roll until the paper
comes out from the top of the printer.
Note that the arrow in the exploded drawing below points towards the
front of the printer.
1-16
Setting Up the Printer
