Printing Specifications
Printing method:
Serial impact dot matrix
Head wire layout:
Serial type 9-pin 1/72 inch
Printing direction:Bidirectional, minimum distance printing (logic seeking)
Printing speed:
Approximately 3.5
LPS
(40 columns,16 CPI, continuous printing)
Approximately 5.4
LPS
(20 columns,16 CPI, continuous printing)
(LPS: Lines Per Second;
CPI:
Characters Per Inch)
,
%
Note:
During
excessive
use, printing stops to protect the print head.
In this case,
the
actual printing
speed
may be slower than that listed above.
Characters per line: See the table below.
Characters per inch: See the table below.
Character Specifications
Number of characters:
Alphanumeric
:
95
Extended graphics:
128
X
8
(tables)
(space pages included)
International:
32
Character structure:
7
X
9 (total horizontal dot positions: 400 half dots)
5
X
9 (total horizontal dot positions:
200
dots)
Character size:
See the table below.
(
*
)
Default font is 7
X
9.
4-2 Reference Information
