Note:
Squeeze the wire clips on the printer
together
until
they
lock in
place on
both
sides of
the
connector.
2.
Connect the other end of the cable to the connector on your computer.
Connecting the Printer to Your Drawer
Follow the procedures below to connect a drawer to the printer only when
you use the printer as a single unit (not connected to an intelligent module).
(Intelligent module connection is available only for the TM-U375.) When
you use the TM-U375 with the intelligent module, refer to the
IT-U Series
User’s Manual
for details.
Use
a drawer
that
matches the
printer
specification.
Using
an
improper
drawer
may damage the drawer as
well
as
the
printer.
1.
Make sure that the printer is turned off.
2.
Plug the cable connector securely into the printer’s drawer kick-out
connector until it clicks.
1-6 Setting Up the Printer
