Note:
To
attach
the
DIP switch cover, insert
the
cover upward
then
slide
the
cover
leftward,
as
shown
in
the
illustration below.
Adjusting the Paper Roll End Sensing Position
The paper near end detector detects when the paper is almost gone by
measuring the diameter of the paper roll. Software programs can use the
ESC
c
4 command to stop printing when the paper is almost gone.
If you want to change the amount of paper remaining when the printer
stops printing, follow the steps below to adjust the paper near end detector.
,
%
Note:
If
the
inner diameter of
the
paper roll core is less
than
10 mm
(0.39
inch),
the
paper roll near-end detector may not work properly.
1.
Open the printer cover and remove the take-up spool.
2.
Determine the point on the paper roll at which you want the near-end
detector to be triggered. Then measure the distance A shown in the
illustration.
Setting Up the Printer
1-23
