Epson WorkForce WF-3520DWF - Aligning the Print Head

A
Make sure that no warnings or errors are indicated in the control panel.
B
Access the Epson Printer Utility 4.
& “Accessing the printer driver for Mac OS X” on page 43
C
Click the Head Cleaning icon.
D
Follow the on-screen instructions.
Using the control panel
Follow the steps below to clean the print head using the product control panel.
A
Make sure that no warnings or errors are indicated in the control panel.
B
Enter Setup mode from the Home menu.
C
Select Maintenance.
D
Select Head Cleaning.
E
Follow the instructions on the LCD screen to continue.
F
Select the color you want to clean, and follow the instructions on the LCD screen to start cleaning.
Note:
Select the color that shows a defect in the nozzle check result.
Aligning the Print Head
If you notice a misalignment of vertical lines or horizontal banding, you may be able to solve this problem by using the
Print Head Alignment utility in your printer driver or by using the product buttons.
Refer to the appropriate section below.
Note:
Do not press y to cancel printing while printing a test pattern with the Print Head Alignment utility.
Using the Print Head Alignment utility for Windows
Follow the steps below to align the print head using the Print Head Alignment utility.
