Erbe EIP 2 Service Manual

3 • Unit description
12 / 56
80116-261  2018-07
Controls
Controls at the front
Fig. 3-1
IMPORTANT! This chapter contains an overview of the controls of the unit(s). The rel-
evant User Manual for the unit(s), knowledge of which is assumed for
servicing work, provides detailed information about how to use the
unit(s).
1
2
3
4
5
6
7
8
9
1 Power switch
2 Quick activation button I (30 % of capacity
1
/ approx. 150 ml/min)
3 Quick activation button II (50 % of capacity / approx. 250 ml/min)
4 Quick activation button III (80 % of capacity / approx. 400 ml/min)
5 Flow display
6 Up / Down buttons
7 Activation button
8 Pump head lid
9 Direction arrow for irrigation liquid
1. Flow in % relative to the maximum flow of 500 ml/min.
