39 / 56
10 • Replacing components
80116-261
2018-07
Change gear motor
Tools • Phillips screwdriver PH 1 (short and long)
• Phillips screwdriver PH 2
• Box wrench size 7
Remove pump head
1. Open pump head lid completely.
2. Undo screws (2).
3. Withdraw pump head toward the front.
WARNING! Unplug the power cord from the outlet before exchanging parts of the
unit or cleaning it.
ATTENTION! Adjustments, technical tests, modifications, maintenance and repair
work may only be performed by Erbe or persons trained by Erbe. If the
work is not performed by trained persons, Erbe accepts no liability and
warranty rights become void.
IMPORTANT! Only use original replacement parts.
