Erbe EIP 2 - Page 40

10 • Replacing components
40 / 56
80116-261  2018-07
Remove housing cover
4. Undo screws in the sub-base (2).
5. Undo screws in the rear panel (3).
6. Remove housing cover carefully, first upward and then to the rear.
4
5
6
4
5
5
