45 / 56
10 • Replacing components
80116-261
2018-07
3. Undo nuts (4) and withdraw main board carefully.
4. Fit new main board in reverse order.
5. Fit front frame in reverse order.
6. Close housing cover.
ATTENTION! Check line voltage setting
The EIP 2 can be operated on a line voltage of 230 V, 120 V, or 100 V.
Therefore, every time the unit is opened always check afterwards
whether the correct line voltage ±10
% is set on the line voltage selec-
tor switch on the main board.
