ergoline VITALITY - Dismantling the acrylic panel and side panel

Dismantling
18/58
Canopy transport locks:
NOTE:
The canopy transport locks must be kept for
further use.
– Do not discard!
– Undo the screws and nuts of the canopy transport
locks.
– Remove the screws and nuts.
Tools: 6 mm Allen Key and 13 mm open-ended wrench
5.1 Dismantling the acrylic panel and
side panel
– Turn the locks (1) through 90°.
– Open the side panel (2).
Tool: 4 mm Allen key
– Unscrew and remove the cover of the rotating
profile.
