09/2022 1028657-00A Installation instructions – 29/58
5.6 Dismantling the air conditioning
– Unplug connector and mains plug of the air con-
ditioning unit cover.
– Remove condensate canister and air condition-
ing unit cover.
– Unplug connectors at ventilation duct.
– Remove both cables from clamps.
Damage to the air conditioner due to transport!
The air conditioner must always be transported
in an upright position as the compressor will
otherwise be damaged.
– Transport in an upright position. Else the re-
frigerant has to gather for at least 8 hours
before switching the system on again..
– Slightly lift air conditioning unit (1) and put on
front left border edge (2).
