ergoline VITALITY - Dismantling the AQUA; AROMA SYSTEM

Dismantling
24/58
5.4 Dismantling the AQUA / AROMA
SYSTEM
Disconnect connector ST74 on component rack.
– Unplug the hoses. To do this, press the blue ring
(1) and take off the hose (2).
– Put protective caps on the hoses (3).
– Loosen the nuts.
– Unhinge the AQUA / AROMA SYSTEM.
Tool: 13 mm double open-ended wrench
