ergoline VITALITY - Removing head end and foot end, rear panel

Dismantling
34/58
5.8 Removing head end and foot end,
rear panel
– Remove head and body ventilation cover.
– Unscrew transport locks (1) at both ends of the
device.
– Take the bolts (2) out downwards from the
pallet.
Tool: 17 mm double open-ended wrench
– Carefully tip over the rear panel with head and
foot end.
– Take out the floor plate.
