09/2022 1028657-00A Installation instructions – 35/58
– Unscrew four (4) screws at each end of the
device.
– Take the head and foot ends away.
Tool: Torx® driver T30
Rear transport locks:
– Undo the nuts on the rear side of the device.
– Remove the securing bolts in a downwards direc-
tion.
Tool: 17 mm double open-ended wrenches
NOTE:
If it is difficult to remove the head and foot
ends, it may help to press the rear wall
lightly to the rear.
Danger of being injured!
The support aids are only designed for the
weight of the rear panel!
– Do not use the support aids to carry the
whole device.
– Attach support aids (TN 701529) to the rear
panel and lift the rear panel from the pallet.
