Clarity Edge Install Guide
40
OBDII power connection
OBDII cable pinouts
Signal Color
GND Black
Sensor IN1 Grey (Remote Trigger)
Sensor IN2 Blue
Sensor IN3 Green-Yellow
Sensor IN4 Green-Black
