SpiroSphere
®
ECG Instructions for Use
Page 10/136
Version 02.02 • 04AUG2022
Start-Up
1. Connect the SpiroSphere to a power
source complying with local regulations.
3. Use the Power On switch located at
the front of the main unit to switch on
the SpiroSphere Main Unit.
LAN
Power Supply
Connection
2. Put the SpiroSphere
Sensor into the slot of
the main unit as shown
below.
Power supply:
The operating status of the device is indicated via an LED on the main unit and on the
SpiroSphere Sensor. Please refer "LED Status SpiroSphere and "LED Status SpiroSphere
Sensor" on page 9.
Mains adapter
