Technical Data Spirometry
Dimension 31.5 x 19.5 x 7.5 cm (L x W x H )
Weight 1.5 kg
Screen Display 16.2 x 12.2 cm
Medical Model: GTM91099-3009-4.0-T2
Power Supply Input: 100 - 240 Vac, 50 - 60 Hz, 1.5 A
Output: 5 V, 6 A
Cable length: 1200 mm
Battery Main Unit Built-in rechargeable lithium-ion battery 3.7 V,
5000 mAh. Battery will last under standard
operating conditions for about 3 h.
Full charging: 2 h
Cycle life: 70% of rated capacity after 350 cycles
SpiroSphere Sensor Built-in rechargeable lithium-ion battery 3.7 V,
640 mAh. Battery will last under standard
operating conditions for about 3 days in standby
and 2.5 h operation.
Full charging: 2 h
Cycle life: 70% of rated capacity after 500 cycles
Protection Class Power Supply Class II
SpiroSphere Sensor Internally powered
Mode of Operation Continuous
Moisture Protection Power Supply IP42
Main Unit IP21
SpiroSphere Sensor IP20
Applied Parts ERT PT, SpiroSphere Sensor Type BF
Application Measuring Pulmonary Function
Interface USB Data Transfer
Bluetooth Data Transfer
WiFi Data Tansfer
Ethernet Data Transfer
3G (optional) Data Transfer
Measuring Principle High-Quality Pneumotach
Operating Ambient Temperature: +10 °C to +35 °C
Relative Humidity: 15 % to 90 %
Barometric Pressure: 700 to 1070 hPa
