ERT SpiroSphere - Sensor Insert and Remove

SpiroSphere
®
ECG Instructions for Use
Page 15/136
Version 02.02 • 04AUG2022
Sensor Insert and Remove
Take care that you have aligned the rail with the sensor holes of the PT tube with the grooved
edge of the SpiroSphere Sensor (as below) when inserting the ERT PT into the SpiroSphere
Sensor:
The ERT PT should be inserted fully without force.
Remove the ERT PT in the direction of the arrow.
rail with sensor holes
