SpiroSphere
®
ECG Instructions for Use
Page 56/136
Version 02.02 • 04AUG2022
Display Inspiratory
Setting options: Preset:
ON, OFF ON
ON means: the inspiratory portion of the Flow-Volume curve is
displayed.
OFF means: the inspiratory portion of the curve will not be displayed.
The setting can be changed during the measurement.
Inspiratory Position
Setting options: Preset:
TLC, RV TLC
The inspiratory and expiratory phase of the Flow-Volume curve can be
referred to TLC or RV.
TLC RV
Display Predicted
Curve
Setting options: Preset:
ON, OFF ON
If activated (ON), a predicted curve will be displayed in the diagram as
reference.
Pred
