Score Board Operation
Scores, Team Fouls, Time Outs
Team Foul
Indicator = ON
56 4 2 12:30
22 2 1
*
T/O SUB
F
Score bench indicators
Add to Scores:
Press the SCORE/+1 button for Team A or Team B to add 1 to the score.
Add to Team Fouls:
Press the TEAM FOULS/+1 button for either team to
add 1 to team fouls.
The score bench has an indicator for each team’s fouls (refer to page 6).
If this feature is not required set the maximum number of team fouls greater than the maximum that will
be used (e.g. 9).
Time Outs - Add to, Subtract from:
Press the TIME OUTS button, a Time Out Request arrow will display (flashing on the LCD screen) first.
This will also turn the Time Out Request arrow on both the score board and the score bench on.
By pressing the same button again after the time out, the Time Out Request will turn off, 1 will be added
(or subtracted) and the time out value displayed on the scoreboard.
Note: The time outs can be programmed to count UP (time outs taken) or DOWN (time outs left). Refer to
page 11 - Functions.
10 2 2 12:30<
12 3 1
Time outs “request”
indicators ON
part of the game
esa.com.au 7
