© ESAB AB 2010
-17-
bp12a1
6 TECHNICAL DATA
EPP-360 460V, 60Hz EPP-360 575V, CSA,
60Hz
Part number 0558 006 832 0558 006 833
Voltage
Current range DC (marking)
200 VDC
10A to 36A
200 VDC
10A to 36A
Output Current range DC (cutting) 30A to 360A 30A to 360A
(100% duty cycle) Power 72 kW 72 kW
Open circuit voltage (OCV) 360 VDC 360 VDC
Voltage (3-phase) 460V 575V
Current (3-phase) 115A RMS 92A RMS
Frequency 60 Hz 60 Hz
Input KVA 91.6 KVA 91.6 KVA
Power 82.5 KW 82.5 KW
Power factor 90.0% 90.0%
Input fuse rec. 150A 125A
Dimensions lxwxh 47.25”x23,75”x40.75”
1200 X 603 X 1035 mm
47.25”x23,75”x40.75”
1200 X 603 X 1035 mm
Weight 1085 Ibs 1085 Ibs
7 INSTALLATION
7.1 General
FAILURE TO FOLLOW INSTRUCTIONS COULD LEAD TO DEATH,
INJURY OR DAMAGED PROPERTY. FOLLOW THESE INSTRUCTIONS
TO PREVENT INJURY OR PROPERTY DAMAGE. YOU MUST COMPLY
WITH LOCAL, STATE AND NATIONAL ELECTRICAL AND SAFETY
CODES.
7.2 Unpacking
S Inspect for transit damage immediately upon receipt.
S Remove all components from shipping container and check for loose parts in
container.
S Inspect louvers for air obstructions.
