DOKP4M4060 3.0 -10- © ESAB/TBi 2021
.
3 Preparing the product for use
3.1 Transport and storage
The following points must be observed during transport and storage:
▪ To prevent danger due to the ESAB MXH PP torch falling, only place it down on substrata that have a
high load-bearing capacity and are stable.
▪ The ambient temperature specifications must be observed.
(see section 2.2)
▪ Protect the ESAB MXH PP torch from moisture and environmental influences.
Important note!
If the ESAB MXH PP is transported and/or stored, the torch neck (1a) must always be
installed for a water-cooled system. Otherwise there is a danger that the cooling water
could get inside the torch body.
3.2 Installation
The following points must be observed during installation:
▪ Carefully remove the packaging; to prevent danger due to the torch falling, only place it down on
substrata that have a high load-bearing capacity and are stable.
▪ Ensure that all ESAB MXH PP torch components are present.
(see section 2.4)
▪ Please observe all sections described below for additional servicing.
3.3 Preparation
Danger!
The supply voltage to the welding machine must be disconnected before starting installation
work. It must be ensured that the entire facility remains switched of for the duration of the
work. There is a risk of fatal electric shock.
You must observe the ‘Safety instructions’ at the beginning of this document.
3.3.1 Equipping the torch
The ESAB MXH PP welding torch can be used for various welding tasks and filler materials. The accessories
integrated into the MXH PP must be individually adapted to each task for the torch to function properly and to
ensure optimum welding results. The necessary work steps are described below.
