ESAB MXH 315 PP - 6 Spare Parts

DOKP4M4060 3.0 -24- © ESAB/TBi 2021
6 Spare parts
Pos.
Part no.
Description
2
0700 025 326
Electronic Trigger, yellow, 2 poles
3a,b, 4
0700 025 327
Handle Push-Pull cpl.
3c
0700 025 328
Screw for handle, 5x12 mm
11
0700 025 329
Knob Potentiometer 10 K OHM
14
0459 990 178
Tension Spring Holder w/o screws
15
0459 990 080
Knurled nut
20
0459 990 081
Pressure roll Holder cpl.
0459 990 082
Pressure roll Holder cpl. for AlSi wire
100
0459 990 051
Feed roll for wire 0.8 mm
0459 990 052
Feed roll for wire 0.9 mm
0459 990 053
Feed roll for wire 1.0 mm
0459 990 054
Feed roll for wire 1.2 mm
0459 990 055
Feed roll for wire 1.4 mm
0459 990 056
Feed roll for wire 1.6 mm
0459 990 057
Feed roll for Al wire 1.0 mm
0459 990 058
Feed roll for Al wire 1.2 mm
0459 990 059
Feed roll for Al wire 1.6 mm
101
0459 990 079
Wire guide 0.8 – 1.6 mm
102
0700 025 321
Inlet guide for wire Ø 0.8-1.0 mm
0700 025 322
Inlet guide for wire Ø 1.2 mm
0700 025 323
Inlet guide for wire Ø 1.6 mm
0700 025 324
Inlet guide for wire Ø 0.8-1.0 mm
0700 025 325
Inlet guide for wire Ø 1.2 mm
130
0700 025 330
Plate for Push Pull with 1 potentiometer
140
0700 025 331
Connection body and motor pre-assembled
MXH PP, water-cooled
0700 025 332
Connection body and motor pre-assembled MXH PP,
gas-cooled
150
0700 025 333
Cable retainer 160 x 3.6mm
160
0700 025 334
Front clamping joint for MIG rubber hose 25x1.5
170
0700 025 335
Knuckle spring, large version
180
0700 025 336
Extension for Push Pull handle, black
190
0700 025 337
O-ring set for PP-TX torch neck gas-/water-cooled
251
0700 025 338
Option: Extension Knob for Poti
Ware parts in bold = standard version
190
O-ring Set for Torch Neck
101
