ESAB MXH 315 PP - Page 29

DOKP4M4060 3.0 -29- © ESAB/TBi 2020
Wear Parts MXH 315 PP
Part no.
Description
Notes
1
0700 025 300
Torch Neck
MXH 315 PP, straight
2
0700 025 301
Torch Neck
MXH 315 PP, 45°
3
0458 464 882
Gas Nozzle
Standard Ø16 mm, Length 80 mm
0458 465 882
Gas Nozzle
Conical Ø14 mm, Length 80 mm
0458 470 882
Gas Nozzle
Straight Ø19 mm, Length 80 mm
5
0460 819 001
Tip Adaptor
M8, Length 31.6 mm
6
0366 397 002
Insulation Bushing
7
0700 025 310
Neck Sleeve
8
0700 300 398
O-Ring 7x1.5 mm
