Chapter2‐ControlSystem
2.1SentinelControlSystem








1. FanButton
o Turnsonandturnoffthefan.

2. LampButton
o Turnsonandturnoffthelamp.

3. SocketButton
o Turnsonandturnofftheelectricalsocket(retrofitkit).
o Themaximumratingofalltheoutletsinthecabinetis5A.
ifoverloaded,thefusewillblow.

4. UVButton
o Althoughpresent,thisfeatureisnotapplicable.

5. Up(▲)andDown(▼)ArrowButton
o Moveupwardsanddownwardsthemenuoptions.
o Increaseanddecreasecorrespondingvalueinsideoneofthemenuoptions.
o Movethesashwindowupwardanddownward(formotorizedsashhood).

6. SetorMuteButton
o Choosethe
menuorsub‐menucurrentlydisplayedontheLCDscreen.
o Proceedtothenextsteporsequenceinsideoneofthemenuoptions.
o SashalarmcanbemutedbypressingSetbutton.

7. MenuButton



o Toenterandexitfromthemenuoptions.
o To
gobacktothepreviouslevelofthemenuoptions.
o Toaccessmaintenancemodefrom“AIRFAIL!”errorcondition.
Alarmisdisabledwhenyouentermenuoptions
Menu
Button
Set/Mute
Button
Up
Button
Down
Button
LCD
Display
Fan
Button
Lamp
Button
Socket
Button
UV
Button
