17
DuctlessFumeHoods
Chapter4–Installation

4.1GeneralRequirements
4.1.1LocationRequirements
Placingthefumehoodinaproperlocationisimportant.Badlocationmayaffecttheperformanceofthe
workstation.

Asseeninthechart,yourequipment’sinternalairflowvelocityisrelatively
low,whencomparedtotheairflowdisturbancespotentiallycausedbythe
openingofadoor,apersonwalkingbyor
adirectexposuretoanair‐
conditioningoutlet.Theseexternalairflowdisturbancescanaffecttheproper
laminarflowofthefumehoodandimpairedtheprotectionofferedbythe
workstation.

Wheninstallingthefumehood,itshouldbelocatedasfarawayaspossible
fromsourcesofairflowdisturbanceand
inanorientationwhichoptimally
shieldsthefumehood’sairflowfromallexternalairflowdisturbances.


Thefollowingrequirementsshouldbetakenintoaccount:
• Thelocationshouldbefarawayfromanykindofheatsource(heaters,fanconverters,etc.)for
facilitatingoptimumoperatingconditions.
• Thereshouldbe
adequatespaceleftforcleaningthebackofthecabinet.
• Thereshouldbeunobstructedaccesstothemainpowersupplypoint.
4.1.1.1PositionRequirements
 
Anypedestriantrafficroutes,thoroughfaresor
walkwaysshouldbeatleast1.0m(3’)fromthefront
ofthefumehood

Allowatleast30cm(1’)clearanceonbothsidesof
thefumehood.

Youshouldnotpositionthefumehoodwherethedistancebetweentheapertureandanydoorwayislessthan
1.5m(5’)orthedistancebetweenthesidepanelandanydoorwayislessthan1.0m(3’).
