6.2AirflowAdjustment
Thespeedcontrollerislocatedintheelectronicspanelwhichisaccessedbyraisingthefrontengineering
accesspanelatthetopofthefrontofthecabinetandthenopeningthedrop‐downcoverbyremovingthetwo
screwsonthefrontleftandrightsidesofthecover.


PlugthemultimeterprobestotheMotorVoltageSamplingPort.Usethemultimetertotakethevoltageair
velocityreading.

Adjusttheairflowbyadjustingthespeedcontroller.Thespeedcontrollermaybedifferentfor230Vand115V
hood.
6.3CertificationandCalibration
Certificationandcalibrationprocedurecanbefoundinthetestreport.
























SpeedController
