5.4ReplacingtheBlower











Forunitswithsecondarybackupfilter,followthese
additionalsteps:
1. Unscrew,openandremovethebackupfilter
clamp
2. Removethesecondarybackupfilter

Thefollowingstepsareapplicabletoallunits:
1. Unscrewandremovethewiremesh
2. Disconnecttheblowerwiring
3.
Unscrewtheblowermounting
4. Takeouttheblowermounting,alongwith
theblower
5. Replaceblower
6. Reversetheabovestepstofinishthe
procedure



5.5ReplacingtheFluorescentLamp
Therearetwofluorescentlampsintheductlessfumehood;theyarelocatedbehindthebluepanelatthetop
ofthesash.

Beforechangingthefluorescentbulbs,ensurethatthecabinetispowereddownanddisconnectedfromthe
electricalsupply.

1. Raisethefrontcoverandlocatethebulbs

2. Removethepowerclipsattheendsofthebulbsbygentlypullingwhilstholdingthebulbsteady
3. Removethebulbsfromthemountingclipsandreplacewithnewones
4. Replacethepowerclipsontheendsofthenewbulbsandensuretheyarefirmlyseated
5. Closethefrontpanel
6. Reconnectthecabinettotheelectricalsupplyandtestthebulbsforproperoperation
5.6Maintenance/ServiceLog
Itisgoodpractice(andinsomecasesregulatoryrequirement)tomaintainalogofallmaintenancework
carriedoutonyourfreezer.

WireMesh
BlowerMounting
