5.2ReplacingtheFilters
5.2.1MainCarbonFilter(s)ChangingProcedureforADC2__,ADC3__andADC4__



1. OpentheFrontPanel
2. OpentheAccessCover
3. PulloutHandleClampingtounlocktheframefilterclamping
4. Removethemaincarbonfilter
5. Reversetheabovestepstofinishtheprocedure
5.2.2MainCarbonFilter(s)ChangingProcedureforADC5__andADC6__


1. OpentheFrontPanel
2. OpentheAccessCover
3. Unscrewtheboltholdingdownthe
framefilterclampingandremoveit
4. Replacethemaincarbonfilter
5. Reversetheabovestepstofinish
theprocedure
 
FrontPanel
AccessCover
CarbonFilter
HandleClamping
Bolt
