Espar Hydronic - Airtronic 5

28 11.2011
QSF-60 Rev. 4
AIRTRONIC 5
For Heater Model Numbers:
AIRTRONIC B5
20 1859
AIRTRONIC D5
25 2361
25 2362
Diagram
Reference
Number
Part Description Operation
Flat Rate
Labour
Code
Time
Allowance
(minutes)
Warranty
Authorization
Number (WA#)
Required
A. Troubleshoot A 30
B. Components Replaced with Heater Installed
1
Electronic Control Unit (ECU)
Replace
A5-B180
10
2
Fuel-Metering Pump
Replace
A5-B480
10
3
Mini-Controller
Replace
A5-B540
15
4
Thermostat
Replace
A5-B545
10
5
Rheostat
Replace
A5-B550
15
6
7-Day Timer
Replace
A5-B565
15
7
Main Wire Harness
Repair
A5-B580
30
7
Main Wire Harness
Replace
A5-B520
30
•
C. Components Replaced with Heater Removed C 60
8
Cable, Glow Plug
Replace
A5-C345
15
9
Combi-Sensor (Overheat / Flame)
Replace
A5-C230
20
10
Blower Unit
Replace
A5-C100
20
11
Seal Ring, Burner
Replace
A5-C085
25
12
Cover, Burner
Replace
A5-C090
25
13
Gasket, Blower
Replace
A5-C145
15
14
Gasket, Burner
Replace
A5-C080
20
15
Heat Exchanger / Burner
Replace
A5-C005
30
•
15
Heat Exchanger/Burner
Clean
A5-C010
15
•
D. Heater Function Test D 30
