Espar Hydronic - Hybernator Compact

41 11.2011
QSF-60 Rev. 4
HYBERNATOR
Hybernator Compact
25 2800 10 0515
25 2800 10 0525
Diagram
Reference
Number
Part Description Operation
Flat Rate
Labour
Code
Time
Allowance
(minutes)
Warranty
Authorization
Number (WA#)
Required
A. Troubleshoot A 30
B. Components Replaced with Heater Installed
1
Hybernator Compact - Controller
Replace
HB-B185
15
2
Hybernator Water Pump Assembly - FM
Replace
HB-B200
20
3
Hybernator Compact – Sensor Harness
Replace
HB-B307
10
4
Hybernator II – Aux FMP Pre Assembly
Replace
HB-B481
20
5
Fuel Metering Pump B/D5
Replace
HB-B480
15
6
AF Heat exchanger I-701 - NPT
Replace
HB-B011
20
8
Hybernator II – in Frame Harness
Replace
HB-B581
20
.
9
Hybernator Compact – Outside Harness
Clean
HB-B582
20
.
10
Hybernator C System Control Harness
Replace
HB-B531
20
.
11
Hybernator Compact – 2 Heater
Harness
Replace
HB-B531
20
.
C. Components Replaced with Heater Removed C 60
12
Electronic Control Unit (ECU in
Hybernator)*
Replace
H10-B180
10
13
Blower Unit
Replace
H4-C100
20
14
Overheat Sensor With Cable
Replace
H4-C240
25
15
Flame Sensor
Replace
H4-C280
15
16
Glow Pin
Replace
H4-C310
15
17
Burner / Flame Tube
Replace
H4-C050
25
18
O-Rings, Sensors
Replace
H4-C245
15
19
O-Ring, Heat Exchanger
Replace
H4-C020
30
20
Seal Kit
Replace
H4-C081
25
21
Heat Exchanger Clean
Clean
H4-C010
15
•
22
Fuel Connection, Glow Pin
Replace
H4-C315
20
•
D. Heater Function Test D 30
