Espar Hydronic - Hydronic 5 S

36 11.2011
QSF-60 Rev. 4
HYDRONIC 5 S
(External Coolant Pump, External Fuel-Metering Pump)
For Heater Model Numbers:
HYDRONIC B5
20 1819
HYDRONIC D5
25 2217
25 2146
25 2218
Diagram
Reference
Number
Part Description Operation
Flat Rate
Labour
Code
Time
Allowance
(minutes)
Warranty
Authorization
Number (WA#)
Required
A. Troubleshoot A 30
B. Components Replaced with Heater Installed
1
Electronic Control Unit (ECU)
Replace
H3-B180
10
2
Coolant Pump
Replace
H3-B200
10
3
Fuel-Metering Pump
Replace
H3-B480
10
4
Push/Pull Switch
Replace
H3-B560
10
5
7-Day Timer
Replace
H3-B565
15
6
Thermostat
Replace
H3-B545
15
7
Main Wire Harness
Repair
H3-B580
30
7
Main Wire Harness
Replace
H3-B520
30
•
C. Components Replaced with Heater Removed C 60
8
Blower Unit
Replace
H3-C100
20
9
Overheat Sensor With Cable Section
Replace
H3-C240
25
10
Flame Sensor
Replace
H3-C280
15
11
Glow Pin
Replace
H3-C310
15
12
Burner / Flame Tube
Replace
H3-C050
25
13
O-Rings, Coolant Pump
Replace
H3-C205
15
14
O-Rings, Sensors
Replace
H3-C245
15
15
O-Ring, Heat Exchanger
Replace
H3-C020
30
16
Seal Kit
Replace
H3-C081
25
17
Heat Exchanger
Clean
H3-C010
15
•
18
Fuel Connection, Glow Pin
Replace
H3-C315
20
•
D. Heater Function Test D 30
