Computer Diagnostic Tool - EDiTH
The following overview is there to help you understand the capability of different diagnostic
hardware. Available are: Diagnostic Unit, EDiTH Basic and EDiTH Expert.
Read out of the current error and the
latest 5 errors
* * *
Running diagnosis at installed heaters
Turn on the heater directly by PC or
Notebook
*
Visualization of the sequence of
operations of the heater/control unit with
display of the operating state and
measured data of each components →
*
Individual test of components
(independent of the control unit) ie.
voltage of glow pin, voltage and speed of
el. motor, fuel metering pump
*
Recognition if heater is high attitude
adjustable
*
Display of general heater data
Recognition if the control unit is high
altitude adjustable
*
Running diagnosis on control unit
Test control unit under real performance
conditions
*
In addition to EDiTH Basic and Expert hardware, additional adapter cables are required for each
type of heater installation. Type of adapters will depend on heater model and installation. For list
of Adaptors and their part numbers please refer to current Espar Product Catalogue.
EDiTH software is updated regularly and the most recent version should be downloaded and
installed from
www.espar.com/help.
