Espar Hydronic - Hydronic 5 Z

38 11.2011
QSF-60 Rev. 4
HYDRONIC 5 Z
(No Coolant Pump, External Fuel-Metering Pump)
For Heater Model Number:
HYDRONIC D5
25 2216
Diagram
Reference
Number
Part Description Operation
Flat Rate
Labour
Code
Time
Allowance
(minutes)
Warranty
Authorization
Number (WA#)
Required
A. Troubleshoot A 30
B. Components Replaced with Heater Installed
1
Electronic Control Unit (ECU)
Replace
H4-B180
10
2
Fuel-Metering Pump
Replace
H4-B480
10
3
Push/Pull Switch
Replace
H4-B560
10
4
7-Day Timer
Replace
H4-B565
15
5
Thermostat
Replace
H4-B545
15
6
Main Wire Harness
Repair
H4-B580
30
6
Main Wire Harness
Replace
H4-B520
30
•
C. Components Replaced with Heater Removed C 60
7
Blower Unit
Replace
H4-C100
20
8
Overheat Sensor With Cable
Replace
H4-C240
25
9
Flame Sensor
Replace
H4-C280
15
10
Glow Pin
Replace
H4-C310
15
11
Burner / Flame Tube
Replace
H4-C050
25
12
O-Rings, Coolant Pump
Replace
H4-C205
15
13
O-Rings, Sensors
Replace
H4-C245
15
14
O-Ring, Heat Exchanger
Replace
H4-C020
30
15
Seal Kit
Replace
H4-C081
25
16
Heat Exchanger
Clean
H4-C010
15
•
17
Fuel Connection, Glow Pin
Replace
H4-C315
20
•
D. Heater Function Test D 30
