Espar Hydronic - Page 45

45 11.2011
QSF-60 Rev. 4
For Heater Model Numbers:
HYDRONIC 10
25 2160
25 2227
Diagram
Reference
Number
Part Description Operation
Flat Rate
Labour
Code
Time
Allowance
(minutes)
Warranty
Authorization
Number (WA#)
Required
A. Troubleshoot A 30
B. Components Replaced with Heater Installed
1
Electronic Control Unit (ECU)
Replace
H10-B180
10
2
Fuel-Metering Pump
Replace
H10-B480
10
3
Push/Pull Switch
Replace
H10-B560
10
4
7-Day Timer
Replace
H10-B565
15
5
Thermostat
Replace
H10-B545
15
6
Main Wire Harness
Repair
H10-B580
30
6
Main Wire Harness
Replace
H10-B520
30
•
C. Components Replaced with Heater Removed C 60
7
Blower Unit
Replace
H10-C100
15
8
Coolant Pump
Replace
H10-C200
15
9
Overheat Sensor
Replace
H10-C255
15
10
Flame Sensor
Replace
H10-C280
20
11
Temperature Sensor
Replace
H10-C305
15
12
Glow Pin
Replace
H10-C310
10
13
O-Ring, Coolant Pump
Replace
H10-C205
10
14
O-Ring, Overheat Sensor
Replace
H10-C265
15
15
O-Ring, Temperature Sensor
Replace
H10-C295
15
16
O-Ring, Heat Exchanger
Replace
H10-C020
25
17
Burner / Flame Tube
Replace
H10-C050
35
18
Burner with Housing
Replace
H10-C055
35
•
19
Heat Exchanger
Clean
H10-C010
15
•
20
Wire Harness, Glow Pin
Replace
H10-C911
15
•
D. Heater Function Test D 30
