Espar Hydronic - Page 49

49 11.2011
QSF-60 Rev. 4
HYDRONIC 16 / 24 / 30 / 35
For Heater Model Numbers:
HYDRONIC 16
25 2165
HYDRONIC 24
25 1817
HYDRONIC 30
25 1818
HYDRONIC 35
25 1819
Diagram
Reference
Number
Part Description Operation
Flat Rate
Labour
Code
Time
Allowance
(minutes)
Warranty
Authorization
Number (WA#)
Required
A. Troubleshoot A 30
B. Components Replaced with Heater Installed
1
Coolant Pump
Replace
LH-B200
10
2
Overheat Sensor
Replace
LH-B255
10
3
Temperature Sensor
Replace
LH-B305
10
4
Push/Pull Toggle Switch
Replace
LH-B560
10
5
7-Day Timer
Replace
LH-B565
15
6
Spare Part Kit, Coolant Pump
Replace
LH-B225
20
7
Main Wire Harness
Repair
LH-B580
30
7
Main Wire Harness
Replace
LH-B520
30
•
8
Combustion-Air Inlet Hood
Replace
LH-B450
10
•
9
Internal Main Wire Harness
Replace
LH-B510
5
•
C. Components Replaced with Heater Removed C 90
10
Flame Tube
Replace
LH-C050
5
11
Burner Motor
Replace
LH-C105
10
12
Fuel Atomizer Nozzle
Replace
LH-C165
10
13
Heat Element, Nozzle
Replace
LH-C170
10
14
Electronic Control Unit (ECU)
Replace
LH-C180
10
15
Ignition Spark Generator
Replace
LH-C195
10
16
Ignition Electrodes
Replace
LH-C335
10
17
Fuel Solenoid Coil
Replace
LH-C500
15
18
Hardware for Fuel Solenoid Coil
Replace
LH-C505
15
19
Baffle Plate / Heat Shield
Replace
LH-C155
5
20
Fuel Pump / Housing
Replace
LH-C495
20
•
21
Heat Exchanger / Water Jacket
Replace
LH-C006
20
•
21
Heat Exchanger / Water Jacket
Clean
LH-C010
20
•
D. Heater Function Test D 30
