16.1. Technical data SwitchPilot
Operating modes:
•NMRA/DCC „Accessory Decoder“ compatible. Address range
from 1 - 2044
•Märklin® Motorola®compatible, up to turnout number 384. k83
compatible. k84 logic
•Power supply by digital command station or separate DC- or
AC-power supply.
•Maximum supply voltage: 18V AC or 24V smooth DC.
Transistor outputs 1 to 4:
•4 outputs with two transistors each, each with 1.5A continuous,
2.0A peak (20 seconds).
•Total maximum load of device: 2.0A continuous, 3.0A peak (20
seconds)
•Overload and short circuit protection for outputs.
•Switching time of each output between 0.06 sec to 2.00 sec or
adjustable for variable. Optional blinking mode and „zoom“-
effect for lighting effects.
Servo outputs:
•2 Servo outputs for RC-servos (e.g.: Graupner® JR, Futaba® or
ESU), adjustable pulse duration between 1.0 msec and 2.0 msec,
positive pulse. Adjustable speed and end positions.
•Power supply for the servos with 5V stabilised supply. Maximum
current draw oft he servo: 250 mA continuous, 500 mA peak (20
seconds)
Feed back:
•Integral RailCom® status feedback reports turnout status via the
tracks and can be displayed on ECoS (amongst others).
Dimensions in mm:
•app. 86mm x 86mm x 25mm
16.2. Technical data SwitchPilot Servo
Operational modes:
•NMRA/DCC „Accessory Decoder“ compatible. Address range
from 1 - 2044
•Märklin® Motorola®compatible, up to turnout number 384. k83
compatible. k84 logic
•Power supply by digital command station or separate DC- or
AC-power supply.
•Maximum supply voltage: 18V AC or 24V smooth DC.
Servo outputs:
•2 Servo outputs for RC-servos (e.g.: Graupner® JR, Futaba® or
ESU), adjustable pulse duration between 1.0 msec and 2.0 msec,
positive pulse. Adjustable speed and end positions.
•Power supply for the servos with 5V stabilised supply. Maximum
current draw oft he servo: 250 mA continuous, 500 mA peak (20
seconds)
Dimensions in mm:
•app. 86mm x 86mm x 25mm
16.3. Technical data SwitchPilot Extension
Operating modes:
•Extension module for SwitchPilot, power is supplied by the latter.
Relay outputs are controlled by SwitchPilot.
Outputs:
•4 Relays with two outputs each (2 x changers), switched as one,
with screw terminals for potential-free switching or power supply
for electro-frogs.
•Maximum load per relay output: 30V AC, 2 A continuous.
Dimensions in mm:
•app. 86mm x 86mm x 25mm
