28
17. List of all supported CVs
CV Name Description Range Value
1 Decoder address 1, LSB Lower 6 bits (bit 0 - 5) of the first decoder address for the outputs 1 to 4. 1 - 63 1
Is used in conjunction with CV 9 in order to store the address.
3 Configuration output 1 Describes the properties of decoder output 1. 0 - 64 8
(only SwitchPilot!) Function Description Value
Variable k83-compatible: output is active as long 0
as the button at the control panel is pressed.
Pulse mode PECO pulse mode for PECO-turnout drives. Reduces 1
the sensitivity of the overload protection.
Pulse mode Duration of „On“-status: multiple of 65 msec. 2 - 31
Alternating Out A and Out B are alternately active. 32 - 63
blinker Duration of „On“-status: multiple of 130 msec
Bi-stable k84-compatable: either Out A or Out B 64
is active, variable
4 Configuration output 2 Describes the properties of decoder output 2 0 - 64 8
(only SwitchPilot!) Function Description Value
- as CV 3 -
5 Configuration output 3 Describes the properties of decoder output 3. 0 - 64 8
(only SwitchPilot!) Function Description Value
- as CV 3 -
6 Configuration output 4 Describes the properties of decoder output 4. 0 - 64 8
(only SwitchPilot!) Function Description Value
- as CV 3 -
7 Version number Internal software version of the decoder - -
8 Manufacturer’s ID Manufacturer’s ID by ESU - 151
Writing value 8 results in a full factory reset of all CVs.
9 Decoder address 1, MSB higher 3 bits (bit 6 - 8) of the first decoder address for the outputs 1 to 4. 0- 7 0
used together with CV 1 to store the address.
