29
CV Name Description Range Value
28 RailCom® configuration Activation and configuration of RailCom-functions 0 - 3 0
Bit Description Value
1 Data transfer on channel 2
No data transfer on channel 2 0
Data transfer on channel 2 permitted 2
2 Confirmation of command on channel 1
No confirmation of command on channel 1 0
Confirmation of command on channel permitted 4
29 Configuration register DCC-configuration settings for SwitchPilot 128
Bit Description Value
3 RailCom® communication
RailCom® communication is switched off 0
RailCom® communication is permitted 8
7 Decoder is DCC Accessory Decoder
(read only, cannot be reprogramed) 128
33 Function output status Current status of function outputs 1 to 4. 0 - 255 -
(only SwitchPilot!) The status of the 8 feedback contacts is only valid if they are wired
correctly to the turnout feedback contacts.
The value of CV 33 can be read and displayed via RailCom®.
Bit Description Value
0 Status output 1, input
FB A 1
1 Status output 1, input
FB B 2
2 Status output 2, input
FB A 4
3 Status output 2, input
FB B 8
4 Status output 3, input
FB A 16
5 Status output 3, input
FB B 32
6 Status output 4, input
FB A 64
7 Status output 4, input FB B 128
