30
CV Name Description Range Value
34 „Zoom“-configuration Defining the outputs 1 - 4 that should show the „fade-in, fade- out“ effect
when turned on or off. „Zoom“ means slow fade-in or fade-out of the
function. This enables you to simulate the prototypical changeover of daylight
signals, hence this function only makes sense for daylight signals. 0 - 31 0
Bit Description Value
0 „Zoom“ - function active for output 1 1
1 „Zoom“- function active for output 2 2
2 „Zoom“- function active for output 3 4
3 „Zoom“- function active for output 4 8
35 Decoder address 2, LSB Lower 6 bits (bit 0 - 5) of the second decoder address for the outputs 5 and 6. 1 - 63 1
(only SwitchPilot!) Is used in conjunction with CV 36 in order to store the address.
36 Decoder address 2, MSB Higher 3 bits (bit 6 - 8) of the second decoder address for the outputs 5 and 6. - 8 8
(only SwitchPilot!) Is used in conjunction with CV 35 in order to store the address.
Value 8 in CV36 switches off the second address (factory setting)
37 Servo 1, rotation speed Running time (speed) of servo 1 from one end position to the following. 0 - 63 15
The running time is always a multiple of 0.25 seconds:1 = 0.25s,...,63 = 15.75s
38 Servo 1, Position „A“ Position A of Servo 1. Value indicates the pulse duration transmitted to the 0 - 63 24
servo.Value 0 = 1msec,..., 63 = 2msec.
39 Servo 1, Position „B“ Position B of Servo 1. Value indicates the pulse duration transmitted to the 0 - 63 40
gesendet wird. Wert 0 = 1ms,..., 63 = 2ms.
40 Servo 2, rotation speed Like CV 37 0 - 63 15
41 Servo 2, position „A“ Like CV 38 0 - 63 24
42 Servo 2, position „B“ Like CV 39 0 - 63 40
43 Servo 3, rotation speed Like CV 37 (only SwitchPilot Servo!) 0 - 63 15
44 Servo 3, position „A“ Like CV 38 (only SwitchPilot Servo!) 0 - 63 24
45 Servo 3, position „B“ Like CV 39 (only SwitchPilot Servo!) 0 - 63 40
46 Servo 4, rotation speed Like CV 37 (only SwitchPilot Servo!) 0 - 63 15
47 Servo 4, position „A“ Like CV 38 (only SwitchPilot Servo!) 0 - 63 24
48 Servo 4, position „B“ Like CV 39 (only SwitchPilot Servo!) 0 - 63 40
List of all supported CVs
