ES592.1 - User Guide 33
6.4 Configuring the ES592.1
The ES592.1 is configured at the PC via a graphic user interface. A web browser
application is used as an interface.
6.4.1 Web Interface
The web interface of the ES592.1 consists of a home page, a page for custom-
ized configuration of the interfaces for the "Wake Up" function and other pages
with information on the status of the ES592.1.
6.4.2 Launching the ES592.1 Web Interface
To launch the ES592.1 web interface:
1. Connect the ES592.1 to the PC.
2. Start the HSP program on the PC.
3. Click Hardware Search.
4. Highlight the ES592.1 configured in the “Hardware” window.
5. Right-click System Configuration.
The default web browser launches the web interface for con-
figuring the ES592.1 with the current IP address of the module
in the address field.
The home page of the ES592.1 web interface is displayed.
6.4.3 Configuring the “Wake Up” Function
To configure the “Wake Up” function:
1. Click Device Configuration.
2. Click Wake Up.
The page for configuring the “Wake Up” function is displayed.
3. Configure the interfaces of the ES592.1 for the “Wake Up” func-
tion.
