ETAS ES592.1 - CAN Interfaces (CAN1;LIN1 and CAN2;LIN2); LIN Interfaces (CAN1;LIN1 and CAN2;LIN2)

ETAS Technical Data
ES592.1 - User Guide 49
CAN Interfaces (CAN1/LIN1 and CAN2/LIN2)
Low-Speed CAN
High-Speed CAN
8.9.5 LIN Interfaces (CAN1/LIN1 and CAN2/LIN2)
ETKs not supported ETKM
ETK3.x
ETK4
ETK6.x
ETK7.0
METK1
METK2
ETK8.0
ETK8.1
ETKS1.0-A
ETKS1.0-B
ETKP1.0
CAN1 and CAN2 2 independent interfaces,
galvanically isolated from each other
and from the other interfaces,
every channel separately configurable
(High-Speed CAN and Low-Speed CAN)
Protocols CAN V2.0a (Standard Identifier),
CAN V2.0b (Extended Identifier)
Transceiver (Physical Layer) TJA1054A
Transfer speed Max. 125 kBaud
Transceiver (Physical Layer) TJA1040
Transfer speed Max. 1 MBaud with a bus length of 20 m
Differential internal resistor Ri 10 kOhm
LIN1 and LIN2 2 independent interfaces,
galvanically isolated from each other
and from the other interfaces,
every channel separately configurable
Specification LIN V2.1
Controller LIN-Core (FPGA)
Transceiver (Physical Layer) MCZ33661EF
Operating mode
1)
Slave
1)
: LIN Monitoring; Send support in preparation.
