ES592.1 - User Guide 63
9.4.3 CAN Termination Resisto
Fig. 9-18 CBCX131-0 Termination Resistor
Order Name Short name Order
Number
CAN 120 & Termination Resistor, 2xDSUB
(9fc+9mc)
CBCX131-0 F 00K 103 786
5
4
3
2
1
6
7
8
9
5
4
3
2
1
9
8
7
6
120 Ohm
