ETAS Technical Data
ES592.1 - User Guide 47
8.9 Electrical Data
8.9.1 Power Supply
8.9.2 Host Interface (HOST)
Operating voltage 7 V to 29 V DC
Power consumption, normal mode
1)
Typ. 500 mA at 14.4 V DC
Power consumption, standby
1)
Typ. 20 mA at 14.4 V DC
Current consumption, total Max. 7 A
(module: max. 3 A, output current per
connection "ETH": nom. max. 2 A)
Energy management On/ off at start/ stop of the Ethernet
communication (on/ off upstream mod-
ule)
Protection
2)
Protected against polarity inversion and
Load Dump protection
1)
: module without power supply of connected modules
2)
: The module may be used only with central load dump protection.
Anschlusstyp Upstream
Anzahl 1 (HOST)
Verbindung 10/100Base-T Ethernet
Protocol TCP/IP
Protocol Ethernet Switching (Layer 2), IEEE802.3
Resolution synchronization 1 s
Compatibility
1)
PC
ES720 Drive Recorder
Network and interface modules:
ES51x, ES592, ES593-D, ES595, ES600
1)
: Support of the ETAS synchronization mechanism
NOTE
To ensure successful initialization of the network card of your PC, refer to
chapter
“Hardware” on page 45.
