8.9.3 Ethernet Interfaces (ETH1 and ETH2)
8.9.4 ETK Interface (ETK)
Type of connection Downstream
Number 2 (ETH1, ETH2)
Connection 10/100Base-T Ethernet
Protocol TCP/IP
Resolution synchronization 1 s
Nom. max. output current per con-
nection "ETH"
Min. 2 A
Power supply of connected mod-
ules
ES4xx Measurement Modules,
ES6xx Measurement Modules, XETKs
Compatibility
1)
Network Module:
ES600
Network and interface modules:
ES51x, ES592, ES593-D, ES595
Measurement modules:
ES4xx, ES6xx, ES930.1
Prototyping and Interface Module:
ES910.3
ECUs with XETK,
ECUs with Ethernet interface
Third party Ethernet devices
2)
1)
: Support of ETAS synchronization mechanism
2)
: No support of ETAS synchronization mechanism
Operating modes Basic, Compatibility, Advanced
ETK protocol speed 8 Mbit/s / 100 Mbit/s
ETK protocol transfer Single Mode / Block Mode
NOTE
The ES592.1 supports all current ETK types.
Exception:
The ETK types not supported by the module are listed in the table. For more
details, refer to the ETAS website.
